Fully Automatic Cylindrical Autoclave

Fully Automatic Cylindrical Autoclave
Price : 25 Lac / one
Get Best Price

MOQ : 1 Piece

Business Type Manufacturer, Exporter, Supplier
Material Stainless Steel
Shape Horizontal
Capacity 78 Liter To 430 Liters
Click to view more

Preferred Buyer From

Location All Countries Except India

Product Details

Temperature
121 Deg. To 134 Deg.
Model No.
GTA-003A
Brand
Genist Technocracy
Insulation Wall
Triple wall
Available Sizes
400 X 600 MM to 500 X 1200 MM (Customized sizes are available)

Material of construction & silent Features

  • Double/Triple walled unit horizontally mounted on a study , heavy Stainless Steel
  • 304/316.
  • Both inner chamber and outer wall made of Stainless Steel.
  • Fitted with Dial thermometer to indicate the inner chamber temperature.
  • Chamber and releasing the steam in atmosphere after use are provided.
  • Lid is made of S.S plate provided with radial locking system.



Gasket

Fitted with silicon rubber gasket.



Door

Sterilizers have single or double door made out or rolled steel lined with stainless steel sheet on both sides.



Component

  • Vacuum Pump & Water Feeding Pump.
  • Fitted with Automatic Pressure Control Switch



Insulation

75MM gap between the wall is filled with special grade glass wool for proper insulation and to avoid heat losses.



Temperature & Power Supply

  • As per the international standards and guidelines our triple walled Horizontal autoclave have a working temperature of 121 C, however for specific requirements our autoclaves can be upgraded to be used for up to 134 C.
  • Pressure is adjustable from 15-20 psi.
  • To work on 440 Volts 3 Phase A.C. Supply. Pressure gauge, safety valve and steam release valve.



Steam Generator

  • Available with separate boiler
  • Automation with Printing Facility



Fully Automatic with PLC controller. Fitted with vacuum breaker to break vacuum in case of formation of vacuum due to steam condensation/Vacuum pump.

Automatic Low Water Level Cut-off Device fitted for general safety of the element.

Printing facility.



Quality & Standards

We are an ISO 9001:2008/WHO-GMP,CE, ISO,CE, ISO 13485:2003 Certified Company with Strict quality control measures conforming to National and International Standards.

Yes! I am interested


Sizes

Size of Inner Chamber Capacity in Liters Load
400X600mm 75 Liters 6.00 KW
450X600mm 100 Liters 6.00 KW
400X1100mm 138 Liters 12.00 KW
400X1200mm 150 Liters 12.00 KW
500X900mm 175 Liters 12.00 KW
500X1200mm 220 Liters 12.00 KW
550X1250mm 300 Liters 12.00 KW
600X1200mm 355 Liters 12.00 KW
650X1200mm 430 Liters 12.00 KW
