Incubator Shaker

Incubator Shaker

MOQ : 1 Piece

Business Type Manufacturer, Exporter, Supplier
No of Shelves 2 Shelves
Model No. GTI-003
Brand Genist
Click to view more

Preferred Buyer From

Location All Countries Except India

Product Details

Material
Stainless Steel
Voltage
220 V
Approval Certificate
GMP, CE, ISO 9001 2008 Certificate
Operating Voltage
220 Volts AC (50 Hz).

Application

  • “GTPL” brings the ultra-high-tech triple-walled Microprocessor controlled, solid-state orbital shaking Incubator down to earth.
  • Specially designed for orbital shaking under controlled Incubations/ temperature required for tissue cultures Fermentation studies, & aging tests, life science applications & growth studies.



Salient Features & Construction

  • Robust construction outer chamber is made of Mild Steel duly pretreated & finished with powder-coated paint for a lasting finish.
  • Inner chamber made of STAINLESS-STEEL SHEET (304 Grade).
  • Fitted with durable coaxial blower for forced air circulation at the triple-walled back to maintain temperature uniformity in the chamber.
  • Outer front double walled door is insulated and is fitted with magnetic tape for airtight closing for no temperature loss, provided with lock and key arrangement.
  • Fitted with Universal Platform to accommodate interchangeable clamps of assorted sizes for different capacity of flasks.
  • Stationery shelves made of Stainless Steel (55-304) for the use of the unit as a standard B.O.D. Incubator can be supplied at extra cost.
  • Doo- operated illumination lamp is fitted inside the chamber for easy visibility.
  • A full view inner plexiglass door enables inspection and monitoring of inner chamber specimens without disturbing the process temperature.
  • High-grade PUF/Glass Wool INSULATION between outer and inner chamber for minimal thermal losses.
  • Heating elements are placed in the path of moving air duly insulated from the body.
  • Control panel having all controls and circuitry are housed at the top fitted with Temperature controller cum Indicator Microprocessor based with LED display for Set Value (SV) & Process Value (PV) to select any desired temperature provided with Voltmeter on the panel to read the incoming voltage.
  • Caster wheel mounted for easy portability.
  • Supplied with cord and plug.

Yes! I am interested


Technical Details

Usable Space in mm: 600 X 600 X 600
Capacity: 8 Cu. Ft
Approx. Volume (LTR): 230 Liters
No. of Shelves: 2
Temperature Range: 5°C above Ambient to 60°C (Resolution 0.1 °C)
TEMP. Controller: by Microprocessor based PID Digital Temperature Indicator Cum Controller
Shaking Amplitude: 25 mm.
RPM Display: Digital
Shaking Speed: Variable speed from 20 RPM TO 250 RPM
TEMP. Accuracy: +1 °C
TEMP. Display: Led Display for set value (SV) AND process value (PV)
Relay: Solid state electronic relay with protective heat sink.
Air Circulation:: By forced convection System
Insulation: By High Density Puf /Glass Wool
Operations: Nearly Silent Operation with Ultra-Low Vibration
Electric Supply: Nearly Silent Operation with Ultra-Low Vibration
