Construction and Salient Features
Table top Bench-top, pre- and post-vacuum autoclave with an automatic temperature control system, self-test system before an operation, self-test mode diagnoses, fully automatic steam ejection and safety device containing safety valve, automatic sterilization cycles, and auto detections for steam sterilization of glass wares and plastic wares.
- Tank Capacity: 20 to 25 liters.
- Stainless steel seamless chamber and epoxy coated chamber cover for more safety.
- Sterilize cycle, dry timer, and indicator lamps display on a panel which allows the operator to visibly acknowledge the phase. It has a program-based controller.
- Safety locking mechanism that prevents opening while the autoclave is under pressure. A complete control panel is provided in the front.
- Steam release valve will exclude cool air and extra steam.
- If electrical AC power is unavailable or is interrupted, the autoclave shall automatically shut off power and buzz to protect the autoclave and instruments.
- The autoclave controls are easy to operate. Just choose the mold and time you want first, and then press start.
- It is thoroughly tested and proven technology. (CE 1023 approved).
- Uniform rubber gasket which endures high pressure and temperature with low dilatability.
Specifications
- Sterilize temperature: 121 °C or 134°C.
- Electrical: AC 220Vor 110V, 2100 watts/ 220V and 1600 watt /110 V.
- Water reservoir capacity: Approx. 5 L.
- Safety device: safety valve, pressure regulator, and overheat protection.
- Maximum Temperature: 150°C.
- Maximum Pressure: 0.25mpa.
- Warranty: One year.
